Model SSS6700 Device Management Tool
for Fieldbus
Specifications
The Device Management Tool monitors and manages
the fieldbus-connected devices. It runs on a personal
computer connected to a control bus or HIS for
builder in the CENTUM CS 1000/CS 3000 systems;
it runs on a personal computer connected to the E
net/Ethernet of the CENTUM CS systems. With the
tool, the users can monitor, manage field devices
(sensors, positioners and analyzers) on a fieldbus,
display, define and maintain parameters. The tool
also has the function to automatically read messages
from field devices on a fieldbus via HIS (ICS), which
allows total management of fieldbus devices.
Features
The Device Management Tool for Fieldbus consists
of the following features:
Message Display
Field Device Status Display
Field Device Listing
Parameter Display and Setting
F05E.ai
Device Management Tool
Common Features
Device Method
*1: Supported by R3.10 or later versions of
Fieldbus Communication Function / Device
Management Tool.
(*1)
Figure Device Management Tool for Fieldbus
Field Device Listing
Manages field devices and lists the defined data for
devices.
Field Device Status Display
Displays field device status, READY/NOT_READY.
Message Display
Displays messages from field devices and ACF11
or ALF111 by acquiring alarms and events of field
devices from HIS (ICS) historical message files.
Parameter Display and Setting
Displays the parameters of function blocks in field devices
and changes them if possible. Tuning parameters
are also displayed and changed.
Device Method (supported by R3.10 or later versions
of Fieldbus Communication Function /
Device Management Tool)
Runs control procedures configured by the device
vendors. It describes procedures to run specific features
for the device such as calibration and reset.
Common Features
Displays the device management history of field devices,
prints reports, and provides security function.
F06E.ai
FCU
HIS
ACF11
PC
Ethernet
Define
parameters
Control Bus
Acquire
messages
Acquire the status of
devices and parameters
HIS for
Builder
Device Management Tool
(*1)
*1: Exaopc OPC Interface (for HIS).
Figure Data Flow of Device Management Tool of
CENTUM CS 1000/CS 3000 (For using ACF11)
F07E.ai
FCU
HIS
ALF111
PC
Ethernet
Define
parameters
Control Bus
Acquire
